Alternate Workflow

1. Create a cross section view.
2. Right-click the section line.
3. Select Split Section.
4. DesignSpark Mechanical creates a default offset.
5. Drag individual section line segments to the desired locations.When you select and drag individual section line segments, the segment you are dragging will snap to and merge with other sections.You can only divide segments that are perpendicular to the principal direction.
6. Continue until you establish all necessary offsets.
